Overview

WiBAS™ G5 Smart represents a technological breakthrough in Intracom Telecom's Point-to-Multipoint ultra-broadband product line. By combining Multi-User MIMO technology, which supports simultaneous connections to multiple terminal stations, with an Advanced Antenna System (AAS) enabling precise beamforming, the WiBAS™ G5 Smart delivers robust, interference-free ultra-broadband connectivity. This TDD all-outdoor PtMP hub radio operates in mm-Wave licensed bands and, utilizing a 200 MHz channel, achieves over 5.6 Gbit/s throughput per sector. Paired with the WiBAS™ G5 GigaConnect+ terminal station (CPE), it provides end-user speeds of up to 2.4 Gbit/s at distances exceeding 8 km from the base station.

Committed to supporting technology neutrality in Fixed Wireless Access networks, the intelligent software of the WiBAS™ G5 Smart ensures seamless coexistence with adjacent 3GPP-based 5G systems. Designed for rapid deployment, the WiBAS™ G5 Smart facilitates innovative ultra-broadband FWA solutions for suburban and rural areas, accommodating up to 120 terminal stations per hub. This makes it an ideal choice for operators building dense FWA networks

Highlights

• Multi-carrier radio delivering ultrafast broadband connections.
• TDD MU-MIMO access method with interference cancellation.
• Operation at area-licensed frequencies:
  • 24 / 26 / 28 / 29 / 31 / 37 / 39 GHz
• Wide channel width: 100 MHz and 200 MHz.
• AAS with beamforming capability.
• Large service area footprint (up to 8.8 km range).
• Robust hitless adaptive modulation up to 1024-QAM.
• Up to 5.6 Gbit/s aggregate sector capacity.
• High terminal density per sector (120 subscribers).
• Highest spectral efficiency reaching 28 bit/s/Hz.
• Low latency for delay-sensitive transmission.
• Flexible mode of operation (Air Frame fully compatible with 5G).
• Support for both direct or wholesale service models.
• Optimized network deployment with PtMP planning and capacity analysis tools enabling also automated Terminal admittance.
• uni|MS™ Radio Link Planning add-on; closed-loop integrated platform.

Applications

• Ultra Broadband Access: High-speed internet for every community.
• FWA Connectivity for MDUs: Deliver ultra-fast, reliable broadband to end-users in apartments, condominiums, and housing complexes, eliminating the need for fiber installation.
• Enterprise Networks: Reliable connectivity for cloud services and business applications.
• Enhanced Service Reliability: Alternative connectivity link for critical applications.
• Transportation Systems: Real-time monitoring, security surveillance, and control center communication.
• Public Safety & Government Services: Video surveillance, remote monitoring, and emergency response.
• Utility Operations: Real-time data collection, predictive maintenance, and outage response.
• Surveillance & Security: Video monitoring for crime prevention and public safety.
• Smart City Solutions: Connected infrastructure for efficient urban management.
• Military Communications: Secure, ruggedized networks for tactical operations.
