Overview

OmniBAS Long Haul (LH) introduces novel solutions for full IP Microwave (MW) transmission at long link ranges with carrier grade availability.

OmniBAS LH addresses effectively the backhaul challenges of mobile networks and extends 5G reach in rural areas and islands. OmniBAS LH can be used to connect remote areas and extend fixed broadband services everywhere. OmniBAS LH can rapidly deploy IP communication and control links for utility companies and governmental agencies, either as the main link or as a back-up path to fiber.

It offers multi-Gigabit IP radio capacity by combining up to 8 carriers with Radio Link Aggregation (RLA) and by supporting market-leading modulations (4096-QAM), while at the same time enables an evolved and smooth migration to an IP architecture. Legacy (TDM) services can also be seamlessly transported over IP with carrier-class reliability and the highest availability.

The advanced radio and smart packet networking features of OmniBAS LH products assure optimal frequency spectrum usage, carrier-grade service delivery and the highest-possible availability at long ranges with exceptional RF performance.

Benefits

• Multi-Gigabit radio capacity
• Use of novel Band-Free Carrier Aggregation ODUs
• Extended link ranges with robust RF performance
• Flexible carrier aggregation up to 8+0
• Maximum spectrum utilization
• Future-proof functionality for 5G backhaul
• Unique solution includes units with smart design for simplified operator logistics
• Powerful end-to-end service & network management

Highlights

A Novel IP LH Family

The OmniBAS™ LH IP MW portfolio allows flexible deployment with a minimal number of models, simplifying operator's logistics and optimizing the Total Cost of Ownership (TCO).

OmniBAS LH is based on the split-mount architecture with modular Indoor units (IDUs) equipped with double modem cards and novel LH Outdoor units (ODUs) at 6,7,8 and 11 GHz, supporting two carriers per unit. The OmniBAS LH portfolio also includes advanced RF combining circulator units and all the required accessories to implement a complete LH link.

• Highly-advanced, modular LH indoor units (LH IDUs):
  • OmniBAS-4Wv2e and OmniBAS-4Wr are part of the OmniBAS IDU portfolio and offer unique synergies with installed base of OmniBAS links.
  • IDUs are equipped with the double modem card PTPv4-d, SW configured for Carrier Aggregation (CA), supporting 2 RF channels over 1 IF interface
  • OmniBAS™-4Wv2e (1RU): modular unit supporting up to four modem cards PTPv4-d and eight radio channels, one Control Card (10GbE, GbE) and one Interface card
  • OmniBAS™-4Wr (2RU): modular unit supporting up to four modem cards PTPv4-d and eight radio channels, one or two (for full redundancy) Control Card (10GbE and GbE), one optional PSU unit (for power redundancy) and two TDM Interface cards (16E1, 32E1)
• Compact high-performance LH Band Free outdoor units (LH ODUs):
  • Frequencies: 6 (6L and 6U), 7/8 and 11 GHz
  • OmniBAS LH ODUs consist of 2 sub-units
    • ODU-CA: Band free, High Power (HP). The novel band free design enables just one model per group of frequencies (6 (6L and 6U), 7/8 and 11 GHz)
    • OAD: OmniBAS Advanced Duplexer for 2 carriers. OAD models are specified per frequency, Channel Size and Sub-band.
  • LH ODUs support dual carrier operation
  • Market-leading modulation up to 4096-QAM
  • Software-defined channel size 7 - 80 MHz
• Compact OmniBAS Circulator Units (OCIRC) enabling 4+0 and 8+0 configurations in one antenna. Thanks to their novel broadband design, just one model is required per group of frequencies (6 (6L and 6U), 7/8 and 11) is needed.
• Full set of ancillaries for complete LH link installations.

NMS

• Managed by state-of-the-art element / network / service unified management suite (uni|MS™).
• Embedded Web Node Manager.
• G.826 statistics for radio paths.
• RMON statistics for Ethernet and radio ports.
• SNMPv3.

Cutting-Edge Features and Capabilities for Multi-Gigabit LH Links

OmniBAS™ LH portfolio combines leading capacity with superior radio capabilities and advanced IP/MPLS functionality to enable LH links with a robust performance

• CA using the double carrier modem and LH ODU units for 2 x 28/40/56 MHz operation
• LH link configurations
  • 2+0, 4+0, 8+0 : using one antenna
  • 4+4SD : using two antennas
  • XPIC 2+0: using one DP antenna
  • XPIC 4+0 : using one DP antenna
• Multi-carrier Radio Link Aggregation (RLA) of up to 8 carriers: 2x(2+0), 4+0, 2x(4+0), 8+0
• Multi-Gigabit radio throughput (without compression), up to 2.2/4.4 Gbps using 4/8 carriers
• Hitless adaptive modulation (up to 4096-QAM) for optimum bandwidth utilization and lower CapEx & OpEx.
• Pre-Distortion (PD) for extended range support and high availability even at higher modulations.
• LDPC and Reed Solomon FEC for robust operation.
• Maximal Ratio combining (MRC) increases system gain by 3dB in SD links
• Advanced Ethernet (L2) traffic handling and QoS:
  • IEEE 802.1Q (Virtual LAN) & IEEE 802.1p (QoS)
  • IEEE 802.1ad (provider bridging, Q in Q)
  • Packet classification per VLAN / P-Bits / DSCP / MPLS exp / IPv6 QoS
  • Eight QoS queues with configurable queue size
  • H-QoS
  • Two-rate, three-color policer (2R3CP)
  • SP / WRR / WFQ scheduling
  • WRED congestion control
  • Egress traffic shaping per port
  • Multilayer header compression
  • Jumbo frames 9,600 bytes
  • Encryption AES 256 (FIPS-197)
  • Automatic ETH-BNM (G.8013 / Y.1731)
  • ITU-T G.8032v2 (Ethernet Ring Protection)
  • IEEE 802.1w (RSTP), IEEE 802.1s (MSTP)
  • IEEE 802.3ad (link aggregation ), static and LACP
  • LLDP
• Efficient Ethernet OAM (IEEE 802.1ag (CFM), ITU-T Y.1731 (PM) , IEEE 802.3ah (EFM)), for end-to-end management.
• System synchronization:
  • Synchronous Ethernet (ITU-T G.8261 / G.8262. G.8264 (ESMC))
  • IEEE 1588v2 TC/BC
  • E1

Applications

OmniBAS™ LH supports a wide range of LH link configurations that can enable carrier grade and extended distance MW connectivity for a variety of applications:

• Mobile 4G / 5G backhaul networks in rural areas and islands.
• Extend fixed broadband services everywhere.
• Resilient network infrastructures.
• Rural networks.
• Communication and control links for utility companies and governmental agencies either as the main link or as a back-up path to fiber.

5G Mobile Backhaul

OmniBAS LH 4+0 / 8+0/ 4+4 SD
