Overview

UltraLink™-BX70 is an ultra-compact all-outdoor Ethernet high-capacity radio operating in the 71-76 GHz part of the E-Band spectrum that is ideally suited for use in cost-sensitive applications.

Using TDD duplexing mode, it achieves throughputs of up to 1.6 Gbit/s bidirectional aggregate, that can be flexibly divided in various configurable directional traffic ratios. It offers a comprehensive set of Carrier Ethernet networking features enabling the formation of network configurations and the delivery of networking services without additional devices. UltraLink™-BX70 is designed to be easily mounted on poles and lamp posts, to enable convenience and speed of installation in traditional telco, as well as street-level environments.

UltraLink-BX70 can be used by Fixed Wireless Access operators/WISPs/ISPs, for offering Gigabit access/connectivity to houses and businesses. UltraLink-BX70 is a cost-optimized E-Band radio using TDD mode, to suit cost-sensitive asymmetrical traffic applications such as GTTx, Enterprise connectivity and camera backhaul.

Benefits

• Ideal for cost-sensitive wireless GTTx and enterprise connectivity services.
• Enables fast and flexible network deployment and services activation.
• Due to its embedded Carrier Ethernet functionality, it can implement complex Ethernet distribution network topologies without external switch equipment.
• Maximizes spectral efficiency for asymmetric traffic profiles in broadband access and camera backhaul networks.
• Operation in low-licensing cost spectrum. Furthermore, in several countries TDD E-Band systems benefit from reduced spectrum fees.

Highlights

Radio features and Configurations

• Operating Frequencies: 71,000 to 76 MHz
• Channel Sizes: 250 MHz
• Duplexing Scheme: TDD
• Ethernet Throughput: Up to 1.6 Gbit/s (aggregate of both directions)
• TDD bidirectional traffic split ratios: 1:1, 3:1, 5:1, 7:1 and inverse
• Modulation types: 4QAM to 256-QAM
• Link Adaptation: Hitless ACM mechanism up to 9 states
• Forward Error Correction: LDPC / Reed Solomon
• Configurations : 1+0

Networking Features

• IEEE 802.1Q (VLAN), IEEE 802.1p
• IEEE 802.1ad (Provider Bridge (Q-in-Q))
• IEEE 802.1w (RSTP)
• IEEE 802.1AX (LAG-Static)
• ITU-T G.8032v2 (ERP)
• Carrier Ethernet E-Line, E-LAN services
• Comprehensive 8 queue QoS. Flow Classification, Ingress Policing, Egress Shaping, Queue Congestion management, multiple Queue scheduling schemes
• IEEE 802.1AB Link Layer Discovery Protocol (LLDP)
• IEEE 802.1ag (Service OAM (CFM)),
• ITU-T Y.1731 (Performance Monitoring)
• IEEE 802.3ah (Link OAM (EFM))

Management & Monitoring

• Embedded Web Server (WebUI)
• Command Line Interface (CLI)
• Intracom Telecom NMS (uni|MS™)

Applications

Fixed Service Network Operators/ ISPs

• Gigabit To The Home/Building/Premises (GTTH/B/P)
• Connectivity for Enterprises/SMEs
• Backhaul of xDSL - DSLAM nodes
• WiFi backhaul

Private Networks

Large organizations with multi-building connectivity needs such as enterprises in the manufacturing sector or services / logistics sector, utilities & mining industries, public sector & governmental agencies, university campus areas, Ports, Logistics depos can deploy UltraLink™-BX70 to:

• Create gigabit/s connections between buildings and/or outpost and/or Checkpoint locations
• Backhaul Surveillance camera traffic to the monitoring /control rooms
• Backhaul WiFi Access points
