Overview

WiBAS™ G5 Dual is the latest FDD addition to the G5 generation of Fixed Wireless Access (FWA) product line. It is an all-outdoor dual-carrier PtMP hub radio operating in the 28 GHz area licensed band and utilizing the most advanced MU-MIMO and interference cancellation techniques to deliver up to double the sector capacity compared to WiBAS™-OSDR.

WiBAS™ G5 Dual base station is ideal for operators needing to deploy dense FWA networks - capable of serving up to 240 terminal stations (per hub). It is based on a software-defined radio platform, which provides future-proof deployments and feature enhancements through software licensing. Operators can instantly increase the total network capacity of an existing WiBAS™ deployment just by replacing legacy WiBAS™-OSDR hubs with this new radio without the need to acquire additional spectrum assets. WiBAS™ G5 Dual combines sophisticated QoS features and robust performance with a highly efficient operation. The electronics - baseband unit / modem / controller and radio circuitry - are all securely accommodated in a lightweight, environmentally-hardened housing that is directly coupled to the antenna.

Highlights

• Operation at area-licensed frequencies (27.50-29.50 GHz).
• Dual-Carrier radio delivering ultrafast broadband connections.
• MU-MIMO access method with interference cancellation techniques.
• Up to 2.6 Gbit/s per sector (112 MHz).
• Robust hitless adaptive modulation up to 1024-QAM.
• Large service area footprint - high terminal density per sector (240 subscribers).
• Exceptional system performance, full hierarchical QoS support and support of various service profiles.
• Multiple power options - direct DC or through PoE injector.
• Optimized network deployment with PtMP planning and capacity.
analysis tools enabling also automated Terminal admittance.

Applications

• Ultra Broadband Access: High-speed internet for every community.
• FWA Connectivity for MDUs: Deliver ultra-fast, reliable broadband to end-users in apartments, condominiums, and housing complexes, eliminating the need for fiber installation.
• Enterprise Networks: Reliable connectivity for cloud services and business applications.
• Enhanced Service Reliability: Alternative connectivity link for critical applications.
• Transportation Systems: Real-time monitoring, security surveillance, and control center communication.
• Public Safety & Government Services: Video surveillance, remote monitoring, and emergency response.
• Utility Operations: Real-time data collection, predictive maintenance, and outage response.
• Surveillance & Security: Video monitoring for crime prevention and public safety.
• Smart City Solutions: Connected infrastructure for efficient urban management.
• Military Communications: Secure, ruggedized networks for tactical operations.
